Special Side-by-Side Door Adjustment
Occasionally after a side-by-side unit is properly installed, blocked and leveled, the refrigerator door top may stick
out farther then the freezer door top, even though the bottom of each door is flush. The adjustment procedure listed
below explains how to correct this. (For video showing this procedure, order part #3756530)
NOTE: Unit must be level before adjusting doors.
Special Side-by-Side Door Adjustment Procedure:
1. First -
Adjust Refrigerator Door Bottom Hinge OUT:
a. Extract shipping screws from refrigerator door bottom hinge. Then, loosen & re-snug bottom hinge mounting
screws.
b. Pull refrigerator door bottom hinge corner out to outer most limit & tighten hinge mounting screws.
NOTE: Check door gasket seal by refrigerator door bottom hinge. If gasket is not sealing, loosen & re-snug
mounting screws, and push refrigerator door bottom hinge corner in slightly until gasket seals.
c. Check door alignment. If refrigerator door top still sticks out farther then freezer door, perform second adjust-
ment.
2. Second -
Adjust Refrigerator Door Top Hinge IN:
a. With a pencil, trace location of refrigerator door top hinge for reference. Extract shipping screws from refrigera-
tor door top hinge, then loosen & re-snug top door hinge mounting screws.
b. Push refrigerator door top hinge corner in to inner most limit & tighten hinge mounting screws.
NOTE: Check door gasket seal around refrigerator
door. If gasket is not sealing, adjust accordingly.
c. Check door alignment. If refrigerator door top still sticks
out farther then freezer door, perform third adjustment.
3. Third -
Adjust Freezer Door Top Hinge OUT:
a With a pencil, trace location of freezer door top hinge
for reference. Extract shipping screws from freezer
door top hinge, then loosen & re-snug top door hinge
mounting screws.
b. Pull freezer door top hinge corner out to outer most limit
& tighten hinge mounting screws.
NOTE: Check door gasket seal by freezer door top
hinge. If gasket is not sealing, loosen & re-snug mount-
ing screws, and push freezer door top hinge corner in
slightly until gasket seals.
c. Check door alignment. If refrigerator door top still sticks
out farther then freezer door, perform fourth adjustment.
4. Fourth -
Adjust Freezer Door Bottom Hinge IN:
a. Extract Phillips head shipping screws from freezer door
bottom hinge. Then, loosen & re-snug bottom door
hinge mounting screws.
b. Push freezer door bottom hinge corner in to inner most
limit & tighten hinge mounting screws.
NOTE: Check door gasket seal around freezer door. If
gasket is not sealing, adjust accordingly.
c. Check door alignment. Minor adjustments may still be
needed at this point, adjust accordingly.
1 - OUT
2 - IN3 - OUT
4 - IN
Figure 2-5. Special Side-by-Side Door Adjustment
