Component Access / Removal
Refrigerator Evaporator Cover (Models 601R, 611,
632, 642, 650)
The bottom of the refrigerator evaporator cover is
secured by slots in the side flanges fitting over pegs at
the bottom of each shelf ladder. At the top, screws hold
the evaporator cover to the evaporator fan shroud. To
access and remove the evaporator cover, the light dif-
fuser must first be removed. Then extract the screws at
the top of the evaporator cover, tilt it forward and lift out.
(See Figure 7-23)
Refrigerator Evaporator Cover (Model 690)
The bottom of the refrigerator evaporator cover is
secured by slots in the side flanges fitting over pegs at
the bottom of each shelf ladder. Below the water reser-
voir area is a screw holding the evaporator cover to a
bracket at the back wall. And, at the top, screws hold
the evaporator cover to the evaporator fan shroud.
(See Figure 7-23)
To access and remove the evaporator cover, the light
diffuser must first be removed. Now extract the screws
at the top of the evaporator cover and below the water
reservoir area. Then, tilt the evaporator cover forward
and lift out.
Refrigerator Evaporator Fan Shroud (Models 601R,
611, 632, 642, 650, 690)
To access the evaporator fan shroud assembly, the light
diffuser and evaporator cover will need to be removed
first. Now extract the mounting screws which secure
the fan shroud assembly to the ceiling of the refrigerator
compartment. Then lower the assembly and disconnect
the wiring for the lights from the wire harness. (See
Figure 7-21 and 7-24)
Refrigerator Evaporator Fan Assembly (Models
601R, 611, 632, 642, 650, 690)
To access the evaporator fan assembly, the light dif-
fuser, evaporator cover, and evaporator fan shroud
assembly will need to be removed. Now, disconnect
the fan motor wire leads from the wire harness, and
extract the mounting screws which secure the fan
assembly to the ceiling. (See Figure 7-25)
Figure 7-23. Evaporator Cover Removal
Screws
Slots & Pegs
(not shown)
Screw
600 Series
(Prior to #1810000)
7-11
#3756270 - Revision B - January, 2006
Figure 7-24. Fan Shroud Assembly Removal
Figure 7-25. Refrigerator Evaporator Fan Removal
Mounting Screws
Wire Connection
