3-68 ENGINE
• Hold the balancer driven gear No. 2 3 with the special tool.
% 09920-53740: Clutch sleeve hub holder
• Turn the balancer driven gear No. 1 4 and align the holes.
• Apply THREAD LOCK SUPER to the bolts (5, 6).
* 99000-32030: THREAD LOCK SUPER “1303”
or equivalent
• Tighten the bolts (5, 6) to the specified torque.
# Balancer driven gear No. 1 bolt 5:
10 N·m (1.0 kgf-m, 7.0 lb-ft)
Balancer driven gear No. 2 bolt 6:
25 N·m (2.5 kgf-m, 18.0 lb-ft)
• Set the balancer shaft so that its slit A is aligned with the
punch mark B on the balancer driven gear.
• Install the balancer driven gear assembly onto the balancer
shaft with the special tool.
% 09913-70210: Bearing installer set (25 mm)

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
