4-24 DRIVELINE/AXLE
FINAL GEAR CASE REASSEMBLY
Reassemble the final gear case in the reverse order of disas-
sembly. Pay attention to the following points.
• Install a new oil seal 1 and O-ring 2 to the bearing stopper.
• Install the final drive gear bearing into the final gear case with
the special tool.
# 09913-75821 : Bearing installer
• Install the oil seal into the final gear case with the special tool.
# 09913-76010: Bearing installer set
$
• Apply SUZUKI SUPER GREASE “A” to the oil seal lip.
' 99000-25010: SUZUKI SUPER GREASE “A”
or equivalent
• Install the final driven gear bearing into the final gear case
with the special tool.
# 09951-16080: Bearing installer
NOTE:
The stamped mark side of bearing face to the driven bevel gear
side.
* Use a new oil seal to prevent oil leakage.
* The lip and spring of the oil seal A should face to the
driven bevel gear side.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
