FI SYSTEM DIAGNOSIS 5-99
IAT SENSOR INSPECTION
The intake air temperature sensor is installed at the front left
side of the air cleaner box. (#5-50)
IAT SENSOR REMOVAL AND
INSTALLATION
• Remove the fuel tank. (#6-3)
• Remove the IAT sensor from the air cleaner chamber.
• Install the IAT sensor in the reverse order of removal.
ECT SENSOR INSPECTION
The engine coolant temperature sensor is installed at the ther-
mostat body. (#5-46)
ECT SENSOR REMOVAL AND
INSTALLATION
• Remove the right air cleaner box. (# 6-13)
• Remove the ECT sensor from the thermostat body.
• Install the ECT sensor in the reverse order of removal.
* ECT sensor: 18 N·m (1.8 kgf-m, 13.0 lb-ft)
TO SENSOR INSPECTION
The tip-over sensor is located under the front seat. (#5-54)
TO SENSOR REMOVAL AND INSTALLATION
• Remove the right frame side cover. (#9-5)
• Remove the TO sensor.
• Install the TO sensor in the reverse order of removal.
NOTE:
When installing the TO sensor, the arrow mark A must be
pointed upward.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
