Suzuki VZR1800 2007 User Manual

7-10 EXHAUST SYSTEM
• Remove the exhaust pipes 6 and the No. 2 muffler 7.
INSTALLATION
Install the exhaust pipe and muffler in the reverse order of
removal. Play attention to the following points:
• Install the exhaust pipes 1 with the No. 2 muffler 2.
#
• Tighten the exhaust pipe bolts and No. 2 muffler bolts and nut
to the specified torque.
$ Exhaust pipe bolt : 23 N·m (2.3 kgf-m, 16.5 lb-ft)
Muffler mounting bolt and nut: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
• Apply gas sealer to the exhaust pipe connectors.
EXHAUST GAS SEALER: PERMATEX 1372
#
Replace the gaskets with new ones.
Replace the exhaust pipe connector with new ones.
Apply PREMATEX 1372.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
