SERVICING INFORMATION 11-3
TROUBLESHOOTING
FI SYSTEM MALFUNCTION CODE AND DEFECTIVE CONDITION
DTC No.
DETECTED
ITEM
DETECTED FAILURE CONDITION CHECK FOR
C00 NO FAULT
––––––––––– –––––––––––
C12
CKP sensor The signal does not reach ECM for 3
sec. or more, after receiving the starter
signal.
CKP sensor wiring and mechan-
ical parts
CKP sensor, lead wire/coupler
connection
P0335
C13/C17
IAP sensor The sensor should produce following
voltage.
0.5 V sensor voltage < 4.85 V
In other than the above range, C13
(P1750) or C17 (P0105) is indicated.
IAP sensor, lead wire/coupler
connection
P1750/P0105
P1750/
P0105
H
Sensor voltage is higher than specified
value.
IAP sensor circuit shorted to
VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
IAP sensor circuit open or
shorted to ground or VCC circuit
open
C14
TP sensor The sensor should produce following
voltage.
0.2 V sensor voltage < 4.80 V
In other than the above range, C14
(P0120) is indicated.
TP sensor, lead wire/coupler
connection
P0120
P0120
H
Sensor voltage is higher than specified
value.
TP sensor circuit shorted to
VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
TP sensor circuit open or
shorted to ground or VCC circuit
open
C15
ECT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C15
(P0115) is indicated.
ECT sensor, lead wire/coupler
connection
P0115
P0115
H
Sensor voltage is higher than specified
value.
ECT sensor circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
ECT sensor circuit shorted to
ground
C21
IAT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C21
(P0110) is indicated.
IAT sensor, lead wire/coupler
connection
P0110
P0110
H
Sensor voltage is higher than specified
value.
IAT sensor circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
IAT sensor circuit shorted to
ground
