2-20 PERIODIC MAINTENANCE
THROTTLE VALVE SYNCHRONIZATION
Inspect the throttle valve synchronization periodically. ($6-23)
COOLING SYSTEM
ENGINE COOLANT LEVEL CHECK
• Keep the motorcycle upright.
• Check the engine coolant level by observing the full and lower
lines on the engine coolant reservoir.
A Full line B Lower line
• If the level is below the lower line, remove the fuel tank
($6-3), left frame head cover and left radiator cover
($9-6), and add engine coolant to the full line from the
engine coolant reservoir filler.
ENGINE COOLANT CHANGE
• Remove the fuel tank. ($6-3)
• Remove the left and right frame head covers, radiator covers
and radiator bottom cover. ($9-6)
• Remove the radiator cap 1.
Inspect initially at 1 000 km (600 miles, 2 months) (E-33
only) and every 12 000 km (7 500 miles, 24 moths).
Inspect every 6 000 km (4 000 miles, 12 months).
Replace engine coolant every 2 years.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
