Suzuki VZR1800 2007 User Manual

5-98 FI SYSTEM DIAGNOSIS
STP SENSOR INSPECTION
The secondary throttle position sensor is installed on the No. 2
throttle body. (#5-61)
STP SENSOR REMOVAL AND
INSTALLATION
• Remove the fuel tank. (#6-3)
• Remove the right air cleaner box. (#6-13)
• Remove the STP sensor and disconnect the coupler 1.
! 09930-11950: Torx wrench
• Install the STP sensor to the No. 2 throttle body. (#6-19)
STP SENSOR ADJUSTMENT
• Adjust the STP sensor. (#6-22)
CKP SENSOR INSPECTION
The signal rotor is mounted on the generator rotor and crank-
shaft position sensor is installed at the inside of the generator
cover. (#4-32)
CKP SENSOR REMOVAL AND
INSTALLATION
• Remove the generator cover. (#3-18)
• Remove the CKP sensor.
• Install the CKP sensor in the reverse order of removal.
(#3-50)

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
