CHASSIS 9-15
REMOVAL AND DISASSEMBLY
• Remove the front wheel. (!9-9)
• Remove the bolts, left and right and front fender.
• Remove the fasteners 1 and bolts 2.
• Remove the head light assembly and disconnect the cou-
plers.
• Loosen the front fork upper clamp bolt 3.
NOTE:
Slightly loosen the front fork cap bolts 4 before loosening the
lower clamp bolts to facilitate later disassembly.
• Loosen the front fork lower clamp bolts.
• Remove the front fork.
NOTE:
Hold the front fork by the hand to prevent sliding out of the steer-
ing stem.
• Separate the front fork cap bolt from the front fork outer tube.
• Compress the front fork spring with the special tool A and
insert the special tool B between the lock nut and the spacer.
% 09940-94930: Front fork spacer holder A
09940-94922: Stopper plate B (11 mm)

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
