DRIVELINE/AXLE 4-7
• Remove the oil seal with the special tool.
# 09913-50121: Oil seal remover
$
• Remove the driven gear stopper with the special tool.
# 09913-70210: Bearing installer set (30 mm)
• Remove the bearings (1, 2) and oil seal housing 3 with the
special tools.
# 09921-20240: Bearing remover set (30 mm)
09941-64511: Bearing remover
09930-30104: Sliding shaft
DAMPER SPRING
Measure the free length of the damper spring. If the length is
shorter than the service limit, replace the spring with a new one.
% Damper spring free length
Service limit: 64.6 mm (2.54 in)
SPEEDOMETER SENSOR ("10-37)
The removed oil seal must be replaced with a new one.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
