8-14 COOLING AND LUBRICATION SYSTEM
• Remove the water pump cover 3.
• Remove the impeller securing bolt by holding the impeller with
a water pump pliers.
• Remove the mechanical seal ring 4 and rubber seal 5 from
the impeller.
• Remove the impeller shaft 6, washer 7 and O-ring 8.
• Remove the mechanical seal with the special tool.
% 09921-20240: Bearing remover set (12 mm)
NOTE:
If there is no abnormal condition, the mechanical seal removal is
not necessary.
!
The removed mechanical seal must be replaced with a
new one.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
