9-20 CHASSIS
• Tighten the damper rod bolt to the specified torque with the
special tool.
% 09940-30221: Front fork assembling tool
# Damper rod bolt: 40 N·m (4.0 kgf-m, 29.0 lb-ft)
FORK OIL
• Place the front fork vertically without spring.
• Compress it fully.
• Pour specified front fork oil up to the top level of the outer
tube.
+ 99000-99044-L01: SUZUKI FORK OIL L01
or an equivalent
• Move the inner rod slowly with the special tool ten times and
more until no more bubbles come out from the oil.
% 09940-52841: Inner rod holder
NOTE:
Refill front fork oil up to the top of the outer tube so that bubbles
are visible while bleeding air.
• Refill specified front fork oil up to the top level of the outer
tube again. Move the outer tube up and down several strokes
until no more bubbles come out from the oil.
• Keep the front fork vertically and wait 5 – 6 minutes.
NOTE:
* Always keep oil level over the cartridge top end, or air may
enter the cartridge during this procedure.
* Take extreme care so as to pump out air completely.
• Hold the front fork vertically and adjust fork oil level with the
special tool.
NOTE:
When adjusting the fork oil level, compress the outer tube fully
without the fork spring.
& Fork oil level: 133 mm (5.2 in)
% 09943-74111: Front fork oil level gauge

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
