CHASSIS 9-27
• Tighten the steering stem nut to the specified torque with the
special tool.
! 09940-14911: Steering stem nut wrench
" Steering stem nut: 45 N·m (4.5 kgf-m, 32.5 lb-ft)
• Turn the steering stem lower bracket about five or six times to
the left and right so that the bearing will be seated properly.
• Loosen the stem nut by 1/4 – 1/2 turn.
NOTE:
This adjustment will vary from motorcycle to motorcycle.
HANDLEBAR HOLDER AND FRONT FORK AND STEERING
STEM UPPER BRACKET
• Install the handlebar holder 1 and handlebar holder bracket
2.
• Temporarily tighten the handlebar holder bolts and handlebar
holder bracket bolts.
• Install the steering stem upper bracket, washer and steering
stem head nut.
• Install the front forks to the steering stem and tighten the front
fork lower clamp bolts temporarily.
• Install the headlight cover brace and headlight back cover.
(#11-50)
• Install the handlebar. (#9-31)
• Tighten the steering stem head nut 3 to the specified torque.
" Steering stem head nut: 90 N·m (9.0 kgf-m, 65.0 lb-ft)
• Remount the front forks. (#9-22)
• Remove the handlebar.
1/4 – 1/2 turn

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
