Suzuki VZR1800 2007 User Manual

2-24 PERIODIC MAINTENANCE
BRAKE FLUID LEVEL CHECK
• Keep the motorcycle upright and place the handlebars
straight.
• Check the brake fluid level relative to the lower limit lines on
the front and rear brake fluid reservoirs.
• When the level is below the lower limit line, replenish with
brake fluid that meets the following specification.
# Specification and classification: DOT 4
$
BRAKE PADS
Front brake
The extent of brake pad wear can be checked by observing the
grooved limit line

A on the pad. When the wear exceeds the
grooved limit line, replace the pads with the new ones.
(!9-52)
%
* The brake system of this motorcycle is filled with a
glycol-based brake fluid. Do not use or mix different
types of fluid such as silicone-based and petro-
leum-based fluids. Do not use any brake fluid taken
from old, used or unsealed containers. Never re-use
brake fluid left over from the last servicing or stored
for a long period of time.
* Brake fluid, if it leaks, will interfere with safe running
and immediately discolor painted surfaces. Check
the brake hoses and hose joints for cracks and fluid
leakage before riding.
Replace the brake pads as a set, otherwise braking
performance will be adversely affected.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
