10-44 ELECTRICAL SYSTEM
NOTE:
If no air bubbles are coming up from a filler port, tap the bottom
of the electrolyte container two or three times.
Never remove the container from the battery.
• After confirming that the electrolyte has entered the battery
completely, remove the electrolyte containers from the bat-
tery. Wait for about 20 minutes.
• Insert the caps 6 into the filler holes, pressing in firmly so that
the top of the caps do not protrude above the upper surface of
the battery’s top cover.
#
For initial charging, use the charger specially designed for MF battery.
#
* Never use anything except the specified battery.
* Once the caps have been installed to the battery, do
not remove the caps.
* Do not tap the caps with a tool such as hammer
when installing them.
CORRECT
INCORRECT
* For charging the battery, make sure to use the charger specially designed for MF battery. Other-
wise, the battery may be overcharged resulting in shortened service life.
* Do not remove the cap during charging.
* Position the battery with the cap facing upward during charging.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
