Suzuki VZR1800 2007 User Manual

– 17 –
DTC No.
DETECTED
ITEM
DETECTED FAILURE CONDITION CHECK FOR
C46
Exhaust con-
trol valve
actuator
EXCVA position sensor produces fol-
lowing voltage.
0.1 V sensor voltage < 4.9 V
In other than the above range, C46
(P1657) is indicated.
When no actuator control signal is
supplied from the ECM, communica-
tion signal does not reach ECM or
operation voltage does not reach
EXCVA motor, C46 (P1658) is indi-
cated. EXCVA can not operate.
EXCVA, EXCVA lead wire/cou-
pler
P1657
P1657
H
EXCVA position sensor voltage is
higher than specified value.
EXCVA position sensor circuit
shorted to VCC or ground circuit
open
L
EXCVA position sensor voltage is
lower than specified value.
EXCVA position sensor circuit
open or shorted to ground or
VCC circuit open
P1658
When no actuator control signal is
supplied from the ECM, communica-
tion signal does not reach ECM or
operation voltage does not reach
EXCVA motor, C46 (P1658) is indi-
cated. EXCVA motor can not operate.
EXCVA, EXCVA motor lead
wire/coupler
C49/C61 PAIR control
solenoid
valve
PAIR control solenoid valve voltage is
not input to ECM.
PAIR control solenoid valve, lead
wire/coupler
P1768/P1656
C60 Cooling fan
relay
Cooling fan relay signal is not input to
ECM.
Cooling fan relay, lead wire/cou-
pler connectionP0480
VZR1800 ('08-MODEL)14-17

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
