Takeuchi TB1160W User Manual

7-2
SPECIFICATIONS
BASIC SPECIFICATIONS
Type 2-Piece boom
MASS
Operating mass*** kg (lb)
Machine with an Outriggers 15070 (33225)
Equipped with a rear blade 14570 (32120)
Maximum Operating mass** kg (lb) 16000 (35274)
PERFORMANCE
Bucket capacity
(Standard bucket)
m
3
(cu. ft.)
Heaped 0.505 (17.83)
Struck 0.369 (13.02)
Slew speed min
-1
(rpm) 10.8 (10.8)
Travel speed
km/h
(mph)
Forward
Creep 0 to 4.3 (2.67)
Low-speed travel 0 to 8.5 (5.28)
High-speed travel
0 to 29.2 (18.14)/ 0 to 20 (12.43)*
Reverse
Creep 0 to 4.3 (2.67)
Low-speed travel 0 to 8.5 (5.28)
High-speed travel
0 to 29.2 (18.14)/ 0 to 20 (12.43)*
Gradeability (degrees) 35
Noise level dB (A)
Sound power level LWA 99
Emission sound pressure level at the
operator’s position (ISO 6396,2008:)
L
pA 75
ENGINE
Manufacturer and model ISUZU AM-4JJ1XZSB-03
Rated output Net (ISO 14396) kW/min
-1
(hp/rpm) 95.0/2200 (127.4/2200)
Displacement ml (cu.in.) 2999 (183)
Starter V-kW 24 - 4.0
Alternator V-kW 24 - 1.2
Battery (IEC 60095-1) V-A·h 12 - 104 X 2
* : Option
** : Maximum operating mass:
Optional parts can be added until the total mass of the machine reaches this mass value.
*** : Equipped with fourth auxiliary hydraulic lines (15kg or 33lb.).
BASIC SPECIFICATIONS
