Takeuchi TB285 User Manual

2-18
CONTROLS
MULTI-DATA DISPLAY
16. LCD
When the starter switch is turned to ON, the
display of hour meter, trip meter or the
various data related to the machine appears.
The initial screen displays the hour meter or
the trip meter.
IMPORTANT: If the vehicle or engine
emergency lamp flashes and a number
appears on the vehivle or engine error
code screen, refer to the “Vehicle error
code list” or “Engine error code list” and
contact your sales or service dealer for
help
Trip/Data switch
Press either the TRIP (1) side or the DATA (2)
side to select a display mode.
•Press
theTRIP(1)sidetodisplaythehour
meter or trip meter.
•PresstheDATA(2)sidetodisplaythe
various data.
TRIP MODE DISPLAY
The display changes as the TRIP (1) side is
pressed as follows.
When the starter switch is turned on, the
mode previously set (before the power-off) is
displayed
1. Hour meter
Displays the total engine running time in
hours.
The rightmost digit indicates tenths of
hours (6 minutes).
Set the inspection and maintenance
intervals according to the time displayed
on the hour meter.
2. Trip meter
A pattern of desired operating hour can be
displayed.
To reset the meter to “0”, press and hold
the TRIP side for three seconds.
3. Returns to the hour meter page.
INSTRUMENT CLUSTER
