Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
f. Check against l
imits:
CHECK that the readout for the measurement Mean readout on
screen is with
in the limits listed for the current vertical scale and
position/offset/generator settings. Enter the value on the test record.
Repeat subs
tep d, using the o ffset and generator settings as is listed
in the table.
CHECK that t
he Mean measurement readout on screen is
within the limits listed for the current vertical scale setting and
position/offset/generator settings. Enter the value on the test record.
Repeat substep d, u sing the negative-polarity offset and generator
settings as is listed in the table.
CHECK that the Mean measurement rea dout on screen is
within the limits listed for the current vertical scale setting and
position/offset/generator settings. Enter the value on the test record.
Repeat substeps c through f until all vertical scale settings, are checked
for the channel under test. (See Table 3-6.)
g. Test all channels: Repeat substeps a through f for all four channels.
3. Disconnect the hookup:
a. Set t
he generator output to 0 V.
b. Disconnect the gene rator from the channel las t tested.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–59
