Tektronix MSO54 Programmer's Manual

Commands listed in alphabetical order
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ET HERnet:IPHeader:DESTinationaddr:
VALue < QString>
TRIGger:{A|B}:BUS:B<x>:ET HERnet:IPHeader:DESTinationaddr:
VALue?
Related Commands
TRIGger:{A|B}:BUS:B<x>:ETHERnet:CONDition
TRIGger:{A|B}:BUS:B<x>:ETHERnet:IPHeader:SOUrceaddr:VALue
TRIGger:{A|B}:BUS:B<x>:ETHERnet:IPHeader:PROTOcol:VALue
Arguments
<QString> is a quoted string of up to 3 2 characters where the allowable
characters are 0, 1, and X. The bits specified in the quoted st
ring replac e the least
significant bits, leaving any unspecified upper bits unchanged.
Examples
TRIGger:A:BUS:B1:ETHERnet :IPHeader:DESTinationaddr:VALue
"000110010010000101101000 00000001"
sets the IP destination address
to trigger on to 192.168.0.1.
TRIGger:A:BUS:B1:ETHERnet :IPHeader:DESTinationaddr:VALue
might return "XXXX XXXXXXXXXXXXXX XXXXXXXXXXXX01".
TRIGger:{A|B}:BUS:B<x>:ETHERnet:IPHeader:PROTOcol:VALue
When the Ethernet trigger condition is set to IPHeader, this command specifies
the value of the 8–bit protocol field that is to be used in the trigger (along with
the source and destination addresses). The default is all X’s (don’t care). The bus
number is specified by <x>.
NOTE. Commonly used protocol values are 1 (ICMP), 2 (IGMP), 6 (TCP) and
17 (UDP).
Conditions
Requires the SR-ENET Triggering and Analysis application.
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ET HERnet:IPHeader:PROTOcol:VALue
<QString>
TRIGger:{A|B}:BUS:B<x>:ET HERnet:IPHeader:PROTOcol:VALue?
2-784 MSO54, MSO56, MSO58, MSO58LP Programmer
