Command groups
Vertical command group
Use the commands in the Vertical Command Group to control the vertical setup of
all live (channel) waveforms for acquisition and to control the display of channel,
reference, and math waveforms. Analog channels are available when analog
probes are attached to FlexChannel inputs.
You can replace VOLts with SCAle in the vertical commands. This provides
program compatibility with earlier models of Tektronix instruments.
Table 2-41
: Vertical commands
Command
Descripti
on
CH<x>? Returns vertical parameters for the specified channel.
CH<x>:BANdwidth Sets or queries the bandwidth of the specifi ed channel.
CH<x>:COUPling Sets or queries the coupling setting for the specified channel.
CH<x>:DESKew Sets or queries the deskew time for the specified channel.
CH<x>:LABel:COLor Sets or queries the color of the specified channel label.
CH<x>:LABel:FONT:BOLD Sets or queries the bold state of the specified channel label.
CH<x>:LABel:FONT:ITALic Sets or queries the italic state of the specified channel label.
CH<x>:LABel:FONT:SIZE Sets or queries the font size of the specifi ed channel label.
CH<x>:LABel:FONT:TYPE Sets or queries the font type of the specified channel label.
CH<x>:LABel:FONT:UNDERline Sets or queries the underline state of the specified channel label.
CH<x>:LABel:NAMe Defines or queries the label for the channel waveform.
CH<x>:LABel:XPOS Sets or queries the X display coordinate for the c hannel waveform label.
CH<x>:LABel:YPOS Sets or queries the Y display coordinate for the c hannel waveform label.
CH<x>:OFFSet Sets or queries the channel offset.
CH<x>:POSition Sets or queries the vertical position for the specified analog channel.
CH<x>:PRObe? Returns all information concerning the probe that is attached to the specified
channel.
CH<x>:PRObe:AUTOZero Autozeros the probe attached to the specified channel.
CH<x>:PRObe:DEGAUSS Starts a degauss cycle of the probe attached to the speci fied channel.
CH<x>:PRObe:DEGAUSS:STATE? Queries w hether the probe attached to the specified channel requires a
degauss operation.
CH<x>:PRObe:FORCEDRange Sets the attached probe to its default range, or it queries the default range
of the probe.
CH<x>:PRObe:GAIN ? Returns the gain of the probe that is attached to the specified channel.
CH<x>:PRObe:ID? Returns the type and serial number of the probe that is attached to the specified
channel.
CH<x>:PRObe:ID:SERnumber? Returns the serial number of the probe that is attached to the specified channel.
CH<x>:PRObe:ID:TYPe? Returns the type of probe that is attached to the specified channel.
CH<x>:PRObe:RESistance? Queries the resistance of the probe that is attached to the specified channel.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-85
