Toro Multi Pro 1750 Service Manual

Multi Pro 1750Page 6 − 10Spray System
Service and Repairs
Spray Pump Drive Belt
1. Spray pump
2. Drive belt
3. Flange nut
4. Adjusting screw
5. Idler pulley
6. Drive pulley
7. Square head set screw (2)
8. Key
9. Hydraulic pump assembly
10. Lock nut (2)
11. Flat washer (2)
12. Flat washer (2)
13. Cap screw (2)
Figure 2
FRONT
RIGHT
27 to 33 ft−lb
(37 to 44 N−m)
1
2
3
4
10
11
12
13
9
5
6
27 to 33 ft−lb
(37 to 44 N−m)
7
8
90 to 100 in−lb
(10 to 12 N−m)
Antiseize
Lubricant
