172 H9 ASD Installation and Operation Manual
Pattern Group 1 Selection 1
Program Pattern Run Speeds
Groups of configured Preset Speeds may be selected and run from this screen.
The execution of grouped Preset Speeds in this manner is called a Pattern
Run.
One to eight user-selected Preset Speeds may be run sequentially for a user-set
number of repetitions. The group of user-selected Preset Speeds is called a
Pattern Group. The Pattern Run function executes the user-set Pattern
Group.
Pattern Group 1 is comprised of up to 8 Selections with each Selection being
1 of 15 possible Preset Speed settings. Skip may be selected to ignore a
Selection.
This parameter allows the user to choose one configured Preset Speed that is to
be used as Selection 1 (of 8) for Pattern Group 1. See F018 for information on
configuring the individual Preset Speeds. Parameters F524 – F530 may be
setup for subsequent Selections 2 – 8.
One Preset Speed number (1 – 15) or Skip is selected for Selection 1 (F523).
The number of times to repeat Pattern Group 1 is selected at F522. Set this
value to 255 to run forever.
Setup Pattern Group 2 at F531 – F539 if more Preset Speed entries are
required.
Pattern Run Setup (for Pattern Group 1)
1. From Program Pattern Run Speeds, select the Preset Speeds that are
to be used as the Pattern Group 1 set of Selections. Select a speed from
the 1 – 15 configured presets; 1 speed number per Selection. Set any
unused Selections to Skip.
2. From Program Pattern Run Pattern Run  Pattern Operation
Selection, enable the Pattern Run mode of operation by selecting Seconds
or Minutes as the unit of measure for the Operation Time setting.
3. From Program Pattern Run Operation Time, set the run-time for
each Preset Speed selected in step 1.
4. Configure two unused discrete input terminals for Pattern Operation
Group 1 and Pattern Operation Trigger Signal.
Note: Activation of the Pattern Operation Group 1 discrete input
terminal is required to enable Pattern Group 1 for use.
Activation of the Pattern Operation Trigger Signal discrete
input terminal starts the Pattern Group 1 pattern run.
5. From Program Pattern Run Pattern Run Pattern 1 Repeat, set to
the number of times that Pattern Group 1 is to be run. Set to 255 to run
forever.
6. From Program Pattern Run Pattern Run Pattern Operation
Mode, set the end-of-pattern command to Reset or Continue.
7. From the Remote mode (Local/Remote light is off), initiate a Ru
n
c
ommand (i.e., F and/or R terminal On).
8. Connect the Pattern Operation Group 1 input terminal to CC.
9. Connect the Pattern Operation Trigger Signal input terminal to CC and
the Pattern Run will start and continue as programmed.
10. Open the Pattern Operation Trigger Signal connection to CC to stop the
Pattern Run before its conclusion if required.
Direct Access Number — F523
Parameter Type — Selection List
Factory Default — Skip
Changeable During Run — No
Minimum — Skip
Maximum — 15
Units — Preset Speed Number
Pattern Group 1
Selection
F523 F524 F525 F526 F527F528 F529 F530
12345678
Preset Speed Number
Skip Skip Skip Skip Skip Skip Skip Skip
11111111
22222222
33333333
44444444
55555555
66666666
77777777
88888888
99999999
10 10 10 10 10 10 10 10
11 11 11 11 11 11 11 11
12 12 12 12 12 12 12 12
13 13 13 13 13 13 13 13
14 14 14 14 14 14 14 14
15 15 15 15 15 15 15 15
F523 F523
