Input Terminal Priority
Program Termi na l Input Special Functions
This parameter is used to allow the Jog and DC Injection Braking input
signals to control the ASD when received via the Terminal Board even though
the system is in the Local mode.
With this parameter enabled, a Jog command or a DC Injection Braking
command received from the Terminal Board will receive priority over
commands from the EOI.
See F260 for more information on using the Jog function.
See F250 – F252 for more information on DC Injection Braking.
Settings:
0 — Disabled
1 — Enabled
Direct Access Number — F106
Parameter Type — Selection List
Factory Default — Disabled
Changeable During Run — No
16-Bit Binary/BCD Input
Program Termi na l Input Special Functions
The extended terminal function is used with the Expansion IO Card Option
(P/N ETB004Z).
This parameter defines the format of the binary or BCD data when using the
option card.
Note: The Expansion IO Card Option 2 option board is required to
use this terminal.
See the Expansion IO Card Option 1 instruction manual (P/N 58685) for
more information on the function of this terminal.
Settings:
0 — None
1 — 12-Bit Binary
2 — 16-Bit Binary
3 — 3-Digit BCD
4 — 4-Digit BCD
5 — Inverted 12-Bit Binary
6 — Inverted 16-Bit Binary
7 — Inverted 3-Digit BCD
8 — Inverted 4-Digit BCD
Selections using 16-bit binary or 4-digit BCD will require the configuration of
terminals S1-S4 on the Terminal Board as binary bits 0 – 3 (F115 – F118). The
Frequency Mode 1 (F004) parameter must be set to Binary/BCD.
For proper scaling of the binary or BCD input, parameters F228 – F231 must be
configured.
Direct Access Number — F107
Parameter Type — Selection List
Factory Default — None
Changeable During Run — No
F106 F107
