198 H9 ASD Installation and Operation Manual
Change Step Selection 2
Program Utilities Display Parameters
The parameter is used to modify the degree that the setting of F707 affects the
output speed changes that are input from the EOI using the Rotary Encoder.
Selecting a zero value here disables this parameter and the resulting non-zero
value of parameter setting F707 is output from the ASD.
Selecting a non-zero value here provides a dividend that will be used in the
following equation resulting in the actual output frequency applied to the motor.
Direct Access Number — F708
Parameter Type — Numerical
Factory Default — 0 (Disabled)
Changeable During Run — Yes
Minimum — 0
Maximum — 255
Operation Command Clear Selection When ST Off
Program Special  Operation Panel Parameters
Upon deactivation of the ST terminal while operating in the Local mode, the
ASD output to the motor will cease— this parameter setting is used to allow for
the reactivation of the motor without user intervention upon the reactivation of
the ST terminal.
Upon reactivation of the ST terminal in this condition the ASD will resume the
Run condition and the motor will start (1 — Retain Run Command).
This feature may be Disabled and the Run command must be re-initiated by the
user for ASD operation (0 — Clear Panel Run Command).
WHEN ENABLED THE ASD WILL RESUME THE RUN CONDITION
WHEN THE ST TERMINAL IS REACTIVATED.
Settings:
0 — Clear Panel Run Command
1 — Retain Panel Run Command
Direct Access Number — F719
Parameter Type — Selection List
Factory Default —
Retain Panel Run
Command
Changeable During Run — Yes
Panel Stop Pattern
Program Special Operation Panel Parameters
While operating in the Local mode this parameter determines the method used
to stop the motor when the stop command is issued via the EOI.
The Decel Stop setting enables the Dynamic Braking system that is setup at
F304 or the DC Injection Braking system that is setup at F250, F251, and
F252.
The Coast Stop setting allows the motor to stop at the rate allowed by the
inertia of the load.
Settings:
0 — Deceleration Stop
1 — Coast Stop
Note: The Stop Pattern setting has no effect on the Emergency Off
settings of F603. This parameter may also be accessed by
pressing the ESC key from the Frequency Command screen.
Direct Access Number — F721
Parameter Type — Selection List
Factory Default — Deceleration Stop
Changeable During Run — Yes
OutputFrequencyDisplayed InternallyCommandedFrequency
F708
F707
-------------=
DANGER
F708 F721
