H9 ASD Installation and Operation Manual 227
Analog Function Assigned Object 21
Program My Function My Function Analog
This parameter plays a role in the setup of the My Function feature by
selecting the functionality to which the adjustment of F962 is applied.
Settings:
0 — Disabled (None)
1 — Acceleration Rate
2 — Upper-Limit Frequency
3 — Acceleration Multiplication Factor
4 — Deceleration Multiplication Factor
5 — Manual Torque Boost
6 — Over-Current Stall (F601)
7 — Thermal Protection
8 — Speed Loop Proportional Gain (F460)
9 — Drooping Gain (F320)
10 — PID Proportional Gain (F362)
See the My Function Instruction Manual (P/N E6581335) for a complete
description of the setup requirements and operational information of the Analog
Function Assigned Object parameter.
Direct Access Number — F964
Parameter Type — Selection List
Factory Default — 0 (Disabled)
Changeable During Run — Yes
Monitor Output Function 11
Program My Function My Function Monitor
This parameter plays a role in the setup of the My Function feature by
establishing the function that is to be recorded and output as the Peak,
Minimum, or Average value as selected at parameter F966.
Select the Monitor Display Input Setting number from Table 10 on pg. 241 to
output the corresponding function.
Use the Communication Number if operating using communications.
See the My Function Instruction Manual (P/N E6581335) for a complete
description of the setup requirements and operational information of the
Monitor Output Function parameter.
Direct Access Number — F965
Parameter Type — Selection List
Factory Default — 2000
Changeable During Run — Yes
Monitor Output Function Command 11
Program My Function My Function Monitor
This parameter plays a role in the setup of the My Function feature by allowing
the user to select the Peak, Minimum, or Normal (Avg.) value of the
parameter F965 selection to be recorded and output as a monitored function.
Settings:
0 — Normal
1 — Peak
2 — Minimum
See the My Function Instruction Manual (P/N E6581335) for a complete
description of the setup requirements and operational information of the
Monitor Output Function parameter.
Direct Access Number — F966
Parameter Type — Selection List
Factory Default — Normal
Changeable During Run — Yes
F964 F966
