Toshiba H9 ASD User Manual

H9 ASD Installation and Operation Manual 217
Input Function Target 3
Program My Function My Function Unit 3
This parameter plays a role in the setup of the My Function feature by
selecting the functionality of the programmable Input Function Target 3
terminal.
This setting assigns the function of the programmable Input Function Target 3
terminal to any one of the user-selectable functions listed in Table 7 on pg. 238,
Table 8 on pg. 239, or Table 10 on pg. 241.
See F977 for more information on this parameter.
Direct Access Number — F916
Parameter Type — Selection List
Factory Default — 0 (Disabled)
Changeable During Run — Yes
Output Function Assigned
Program My Function My Function Unit 3
This parameter plays a role in the setup of the My Function feature by
selecting the functionality of the Output Function Assigned terminal.
This setting assigns the function of the programmable Output Function
Assigned data location to one of the functions listed in the Input Setting field
of Table 8 on pg. 239.
Settings:
0 – 3099
See the My Function Instruction Manual (P/N E6581335) and F977 for more
information on this parameter.
Direct Access Number — F917
Parameter Type — Selection List
Factory Default — 0 (Disabled)
Changeable During Run — Yes
My Function Percent Data 1
Program My Function My Function Data
This parameter is used to set the trigger threshold level of the analog signal of
the My Function Percent Data 1.
The analog signal is selected using the Input Setting number from Table 8 on
pg. 239.
Once the assigned output value reaches the threshold setting of this parameter
the output value is transferred to My Function Out 1.
See the My Function Instruction Manual (P/N E6581335) and F977 for more
information on this parameter.
Direct Access Number — F918
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — Yes
Minimum — 0.00
Maximum — 200.00
Units — %
My Function Percent Data 2
Program My Function My Function Data
This parameter is used to set the trigger threshold level of the analog signal of
the My Function Percent Data 2.
The analog signal is selected using the Input Setting number from Table 8 on
pg. 239.
Direct Access Number — F919
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — Yes
Minimum — 0.00
Maximum — 200.00
Units — %
F916 F919
