H9 ASD Installation and Operation Manual 201
Trace Cycle
Program Utilities Trace
This parameter sets the record time for the Trace Data events selected at F742
– F745.
See F740 for more information on this parameter setting.
Settings:
0 — 4 mS
1 — 20 mS
2 — 100 mS
3 — 1 Second
4 — 10 Seconds
Direct Access Number — F741
Parameter Type — Selection List
Factory Default — 100 mS
Changeable During Run — Yes
Trace Data 1
Program Utilities Trace
This parameter is used to select the Trace Data 1 item from Table 9 on pg. 240
to be read and stored in accordance with the setup of parameters F740 and
F741.
See F740 for more information on this parameter setting.
Direct Access Number — F742
Parameter Type — Selection List
Factory Default — Output Frequency
Changeable During Run — Yes
Trace Data 2
Program Utilities Trace
This parameter is used to select the Trace Data 2 item from Table 9 on pg. 240
to be read and stored in accordance with the setup of parameters F740 and
F741.
See F740 for more information on this parameter setting.
Direct Access Number — F743
Parameter Type — Selection List
Factory Default — Freq. Reference
Changeable During Run — Yes
Trace Data 3
Program Utilities Trace
This parameter is used to select the Trace Data 3 item from Table 9 on pg. 240
to be read and stored in accordance with the setup of parameters F740 and
F741.
See F740 for more information on this parameter setting.
Direct Access Number — F744
Parameter Type — Selection List
Factory Default — Output Current
Changeable During Run — Yes
Trace Data 4
Program Utilities Trace
This parameter is used to select the Trace Data 4 item from Table 9 on pg. 240
to be read and stored in accordance with the setup of parameters F740 and
F741.
See F740 for more information on this parameter setting.
Direct Access Number — F745
Parameter Type — Selection List
Factory Default — DC Voltage
Changeable During Run — Yes
F741 F745
