H9 ASD Installation and Operation Manual 237
Table 6. Output Terminal Assignments for the FP, AM, FM, MON1, and MON2 Output Terminals.
Output Meter Terminal Assignments and Display Item Selections
Selection/
Comm Number
Terminal Assignment Name
Selection/
Comm Number
Terminal Assignment Name
0 Output Frequency 30 100% Meter Adjust Value
1 Frequency Reference 31 Data from Communications
2 Output Current 32 185% Meter Adjust Value
3 DC Bus Voltage 33 250% Meter Adjust Value
4 Output Voltage 34 Input Watt Hour
5 Compensated Frequency 35 Output Watt Hour
6 Speed Feedback (Realtime) 45 Gain Display
7 Speed Feedback (1 Sec Filter) 46 My Function Monitor 1 Without Sign
8 Torque 47 My Function Monitor 2 Without Sign
9 Torque Command 48 My Function Monitor 3 With Sign
11 Torque Current 49 My Function Monitor 4 With Sign
12 Excitation Current 50 Signed Output Frequency
13 PID Feedback Value 51 Signed Frequency Reference
14 Motor Overload Ratio 52 Signed Compensated Frequency
15 ASD Overload Ratio 53 Signed Speed Feedback (Realtime)
16 DBR Overload Ratio 54 Signed Speed Feedback (1 Sec Filter)
17 DBR Load Ratio 55 Signed Torque
18 Input Power 56 Signed Torque Command
19 Output Power 58 Signed Torque Current
23 Option V/I Input 59 Signed PID Feedback Value
24 RR Input 60 Signed RX Input
25 V/I Input 61 Signed RX2 Option (AI1) Input
26 RX Input 62 Signed 100% Meter Adjust Value
27 RX2 Option (AI1) Input 63 Signed 185% Meter Adjust Value
28 FM Output 64 Signed 250% Meter Adjust Value
29 AM Output
