Triumph 1050 Sprint User Manual

22
General Information
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Odometer/Trip Meter
1. Odometer/Trip meter display
2. Set button
3. Trip button
The odometer shows the total distance that
the motorcycle has travelled.
The odometer and two trip meters are
located in the same LCD display as the clock
and trip computer. Either trip meter shows
the distance that the motorcycle has travelled
since the meter on display was last reset to
zero.
Use the 'trip' button to switch between the
odometer and trip meter display modes.
Press the 'trip' button repeatedly until the
desired display is visible. The display will scroll
through in the order:
•Odometer
• Trip Meter 1
• Trip Meter 2
To reset either of the trip meters, select and
display the trip meter to be zeroed then press
the 'trip' button for 2 seconds. After
2 seconds, the trip meter on display will reset
to zero.
Warning
Never allow engine rpm to enter the
'red zone' as severe engine damage may
result.
km/h
12 3
ccqu
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.

Triumph 1050 Sprint Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Brakes	Twin 320mm floating discs, 4 piston calipers
Rear Brakes	Single 255mm disc, 2 piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	210 kg
Exhaust	Stainless steel 3 into 1 exhaust system
Ignition	Digital - inductive type
Frame	Aluminum beam perimeter
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload
Rake/Trail	24 degrees
Dimensions	Length: 2, 115 mm, Width: 760 mm, Height: 1, 210 mm
