Triumph 1050 Sprint User Manual

25
General Information
After a short time, the clock's hour display will
start to flash.
To reset the hour display, ensure that the
hour display is still flashing then depress the
'scroll' button to change the setting. Each
individual press will change the setting by
one digit. If the button is held, the display will
continuously scroll through in single digit
increments.
When the correct hour display is shown,
press the 'set' button. The minutes display will
begin to flash. The minutes display is
adjusted in the same way as for the hours.
Once both hours and minutes are correctly
set, press the 'set' button to confirm the
setting. The display will cease to flash.
Coolant Temperature Gauge
1. Coolant temperature gauge
The coolant temperature gauge indicates the
temperature of the engine coolant.
When the ignition is switched on, all 10 bars
of the display will be shown. When the
engine is started from cold the display will
show 1 bar. As the temperature increases,
more bars will be shown in the display.
The normal temperature range is between
3and 6 bars.
If the coolant temperature becomes too high,
the display will show 9 bars and will start to
flash. The high coolant temperature warning
light in the tachometer will also be
illuminated.
If the coolant temperature increases further,
all 10 bars of the display will flash. The high
coolant temperature warning light in the
tachometer will remain illuminated.
ccnj
1

Triumph 1050 Sprint Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Brakes	Twin 320mm floating discs, 4 piston calipers
Rear Brakes	Single 255mm disc, 2 piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	210 kg
Exhaust	Stainless steel 3 into 1 exhaust system
Ignition	Digital - inductive type
Frame	Aluminum beam perimeter
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload
Rake/Trail	24 degrees
Dimensions	Length: 2, 115 mm, Width: 760 mm, Height: 1, 210 mm
