Triumph 1050 Sprint User Manual

53
How to Ride the Motorcycle
Braking
1. Front brake lever
1. Rear brake pedal
Warning
WHEN BRAKING, OBSERVE THE
FOLLOWING:
Close the throttle completely, leaving the
clutch engaged to allow the engine to help
slow down the motorcycle.
Change down one gear at a time such that
the transmission is in first gear when the
motorcycle comes to a complete stop.
When stopping, always apply both brakes
at the same time. Normally the front brake
should be applied a little more than the
rear.
Change down or fully disengage the clutch
as necessary to keep the engine from
stalling.
Never lock the brakes, as this may cause
loss of control of the motorcycle and an
accident.
2
1
3
4
1
jaim
Warning
For emergency braking, disregard down
changing, and concentrate on applying the
front and rear brakes as hard as possible
without skidding. Riders should practice
emergency braking in a traffic-free area.
(See ABS warnings below/over.)
Triumph strongly recommends that all
riders take a course of instruction, which
includes advice on safe brake operation.
Incorrect brake technique could result in
loss of control and an accident.
1
ceyr

Triumph 1050 Sprint Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Brakes	Twin 320mm floating discs, 4 piston calipers
Rear Brakes	Single 255mm disc, 2 piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	210 kg
Exhaust	Stainless steel 3 into 1 exhaust system
Ignition	Digital - inductive type
Frame	Aluminum beam perimeter
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload
Rake/Trail	24 degrees
Dimensions	Length: 2, 115 mm, Width: 760 mm, Height: 1, 210 mm
