Triumph 1050 Sprint User Manual

26
General Information
Fuel Gauge
1. Fuel gauge
The fuel gauge indicates the amount of fuel
in the tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel in the tank.
When the fuel tank is full, all 10 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
When 2 bars are displayed, the low fuel
warning light will illuminate. This indicates
there are approximately 4.0 litres of fuel
remaining in the tank and you should refuel
at the earliest opportunity.
After refuelling, the fuel gauge and range to
empty information will be updated only while
riding the motorcycle.
Depending on the riding style, this could take
approximately 5 minutes.
Caution
Do not continue to run the engine if either
of the high temperature warnings are
displayed as severe engine damage may
result.
ccni
1

Triumph 1050 Sprint Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Brakes	Twin 320mm floating discs, 4 piston calipers
Rear Brakes	Single 255mm disc, 2 piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	210 kg
Exhaust	Stainless steel 3 into 1 exhaust system
Ignition	Digital - inductive type
Frame	Aluminum beam perimeter
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload
Rake/Trail	24 degrees
Dimensions	Length: 2, 115 mm, Width: 760 mm, Height: 1, 210 mm
