Labels
L
ABELS
These labels shall be present and in good condition before operating the machine. Be sure to read, under-
stand and follow these labels when operating the machine.
HYDRAULIC FLUID
060197-000
!
107052-000
26,3 kg +
014222-903
THIS PLATFORM IS
NOT INSULATED
DIESE ARBEITSBÜHNE
IST NICHT ISOLIERT
CETTE PLATEFORME
N'EST ISOLEE
100102-900
066522-900
010076-901
DANGER
FAILURE TO READ, UNDERSTAND AND OBEY THE
FOLLOWING SAFETY RULES WILL CAUSE DEATH
OR SERIOUS INJURY.
TIP-OVER HAZARDS
ELECTROCUTION HAZARD
FALL HAZARD
DO NOT elevate or drive
elevated on slopes or soft ground
DO NOT drive into holes or over
drop offs.
Do not exceed 113Kg (1 person)
on the slide out platform.
DO NOT climb on guardrail
Make sure guardrails are fastened
securely.
Secure gate across enterance.
DO NOT use ladders or scaffolding
on the platform.
DO NOT climb down linkage.
503723-000
503723-000
1 060197-001
2 101210-000
3 505049-000
5 005223-909
6 505077-000
7 505078-000
9 107052-000
11 010076-901
12 505079-000
15 062562-951
16 505076-000
19 014222-903
20 100102-900
21 066522-900
22 068635-001
23 501453-000
24 503723-000
25 107053-000
