Section 3 - Service & Repair General Lubrication
505115-000 Pa
g
e 3-7
3-5 G
ENERAL
L
UBRICATION
Figure 3-3: Lubrication Points
• Apply grease to each grease fitting.
• Apply one or two drops of motor oil to each
bearing.
1. King Pin Bearings
2. Steering Linkage
3. Wheel Bearings
G Grease # Oil
G
3
1
2
