Upright TM 12 Series User Manual

Pa
g
e 6-25
Illustrated Parts Breakdown - Electrical Assembly
505115-000 TM12 PARTS MANUAL
Electrical Assembly
505008-000
Item Part Description QTY.
1 503800-000 HYDRAULIC MANIFOLD BLOCK 1
2 505006-000 LOWER CONTROL BOX 1
3 065709-001 I/O BOARD 1
4 057586-000 HORN 1
5 057328-000 BEEPER 1
6 058912-000 TILT SENSOR 1
7 505072-000 PROXIMITY SWITCH 1
8 505005-000 UPPER CONTROL BOX 1
9 501074-000 BATTERY 4
10 069199-001 BATTERY CHARGER 1
11 057485-000 LINE CONTACTOR 1
12 058912-000 MAIN FUSE 1
13 101230-000 PUMP MOTOR 1
14 065708-001 MICRO MOS 1
15 505130-000 ELECTRICAL HARNESS,I/O BOARD- HYD BLOCK 1
16 505131-000 ELECTRICAL HARNESS,I/O BOARD- LCB 1
17 505132-000 ELECTRICAL HARNESS,I/O BOARD- CHASSIS 1
18 505133-000 ELECTRICAL HARNESS,I/O BOARD- UCB 1
19 505134-000 ELECTRICAL HARNESS,I/O BOARD- MICRO MOS 1
Item Part Description QTY.
