Upright TM 12 Series User Manual

Pa
g
e 6-19
Illustrated Parts Breakdown - Hydraulic Assembly
505115-000 TM12 PARTS MANUAL
Hydraulic Assembly
505007-000
Item Part Description QTY.
1 501999-000 DRIVE MOTOR 2
2-- -
3 505037-000 HYDRAULIC CYLINER (LIFT) 1
4 505101-000 HYDRAULIC HOSE (MOTOR TO MOTOR) 1
5 505099-000 HYDRAULIC HOSE (BLOCK TO MOTOR, LH) DI - LH 1
6 505100-000 HYDRAULIC HOSE (BLOCK TO MOTOR, RH)D2 - RH 1
7 505108-000 HYDRAULIC HOSE (LIFT CYL DRAIN - TANK) 1
8 502342-000 PRESSURE SWITCH (K65 N/C) 1
9 502341-000 T - PIECE (3/8 - 3/8 - 1/4) M/M/M
10 505110-000 HYDRAULIC HOSE (T PIECE - FLOW REGULATOR) 1
11 505035-000 HYDRAULIC CYLINDER, STEER / BRAKE 2
12 505118-000 HYDRAULIC HOSE(BLOCK - STEER CYL, FULL B) 1
13 505094-000 HYDRAULIC HOSE(BLOCK - STEER CYL, ANNULAR)
14 505111-000 HYDRAULIC BLOCK (FLOW DIVIDER/REGULATOR) 1
15 505098-000 HYDRAULIC HOSE (FLOW REG - LIFT CYL) 1
16 505112-000 HYDRAULIC HOSE (RETURN LINE T - FLOW REG) 1
17 505125-000 T PIECE (RETURN LINE) 1
18 505104-000 HYDRAULIC HOSE (RETURN T - FILTER) 1
19 - - -
20 057107-000 FILTER (HYDRAULIC OIL) 1
21 - - -
22 505107-000 HYD HOSE (BLOCK - BRAKE CYL, ANNULAR) 1
23 503800-000 HYDRAULIC MANIFOLD BLOCK 1
24 55106-000 HYDRAULIC HOSE (DRAIN T - BRAKE FULL BORE) 1
25 505109-000 HYDRAULIC HOSE (DRAIN T - TANK) 1
26 505103-000 HYDRAULIC HOSE (PUMP - BLOCK, PRESSURE) 1
27 505102-000 HYDRAULIC HOSE (TANK - PUMP, SUCTION) 1
28 505095-000 HYDRAULIC HOSE (BLOCK - POTHOLE T-PIECE) 2
29 505105-000 HYDRAULIC HOSE (FILTER - TANK, RETURN) 1
30 505096-000 HYDRAULIC HOSE (TEE - POTHOLE CYL) 3
31 505097-000 HYDRAULIC HOSE (TEE - POTHOLE CYL) 1
32 503782-000 TEE PIECE (POTHOLE SYSTEM) 2
33 505036-000 HYDRAULIC CYLINDER (POTHOLE) 2
34 - - -
35 505013-000 TANK (HYDRAULIC RESERVOIR) 1
36 503782-000 TEE PIECE (CYL DRAIN) 1
Item Part Description QTY.
