3.11.7 OUTPUT Buffer (Master PLC)
3.11.7.1 Overview
Buffer
Data
model
Index
Contents (MSB) Contents (LSB)
0
1
Pressure setpoint
2
3
Position setpoint
4
5
6
7
8
9
Not used – reserved
10
Not used – reserved
Control mode setpoint
11
Not used – reserved
General control setpoint
12
13
14
15
Not used – reserved
16
17
Cluster valve freeze position setpoint
18
Not used – reserved
Cluster valve freeze address setpoint
19
Not used – reserved
Cluster valve freeze control setpoint
16 bit
(Word)
20
Not used – reserved
Cluster valve monitoring address setpoint
Note: For data consistency make sure your master PLC is supporting “block guarantee of cyclic data per station”.
