3-44 BA 50Z3/6003 en – Edition 4.3 * * 5003b330.fm
Operation
Backrest adjustment
☞ Sit down on the seat.
☞ Adjust by pulling lever D in the direction of the arrow.
☞ Lean back to push the backrest into the required position.
☞ The lever must engage in the required position.
Adjusting the head rest
☞ The head rest can be adjusted vertically by raising or lowering it in notched positions.
☞ Inclination can be adjusted by pressing the head rest forward or backward.
Horizontal suspension
Shocks in driving direction are absorbed more easily.
☞ Slide the seat fully back to enable the horizontal suspension.
Fig. 100: Backrest adjustment
D
Fig. 102: Horizontal suspension
Pos.
Function
1
Horizontal suspension OFF (point toward front window)
2
Horizontal suspension ON (point toward rear window)
