BA 50Z3/6003 en – Edition 4.3 * 5003b330.fm 3-53
Operation
Opening the lower front window
☞ Press levers D on the left and right, and pull the lower front window upward with both
handles E.
☞ Make levers D lock into both recesses F.
Closing the lower front window
☞ Keep levers D on the left and right pressed and pull the lower front window downward.
☞ Release levers D and make them lock into place on either side.
Fig. 117: Lower front window
Fig. 118: Opening the lower front window
D
F
E
Fig. 119: Closing the lower front window
D
