Introduction
1.2 Machine overview
Fig. 1: Machine outside views
1 Roof lights (option)
2 Working light on boom
3 Travel gear
4 Stabilizer blade
5 Engine cover
6 Handles
7 Tank filler inlet
8 Exhaust pipe
9
Eye hook for loading/tying down the
machine
10 Rotating beacon (option)
11 Auxiliary hydraulics
12 Tank cover
13 Door arrester
14 Door handle and lock
15 Counterweight (option)
1
3
5
9
2
7
10
8
4
6
11
8
1
12
13
14
15
11
