BA 50Z3/6003 en – Edition 4.3 * 5003b330.fm 3-51
Operation
3.31 Front window (from serial no. AD06527)
Danger!
Opening and closing the front window –
Crushing hazard.
☞ Stay clear (extremities, clothing) of the window run.
☞ Ensure that no-one hits the window with their head as you open and close it.
☞ Always open and close the front window by means of both handles B.
☞ Levers A must always engage in the locks as you open and close the window.
☞ Fold up the control lever base before opening or closing the front window,
in order to avoid any unintentional operation or movement of the machine.
Opening the front window
☞ Keep levers A pressed on the left and right, and pull the front window upward with both
handles B.
Fig. 112: Front window
Fig. 113: Opening the front window
A
B
