Maintenance
5.21 Fluids and lubricants
Component/application Fluid/lubricant Specification
Season/tem-
perature
Capacities
1
1. The capacities indicated are approximate values; the oil level check alone is relevant for the correct oil level
Capacities indicated are no system fills
50Z3 6003
Diesel engine Engine oil
2
2. According to DIN 51511 (API CF, CF-4, CI-4; ACEA E3, E4, E5; JASO DH-1).
SAE10W-40
–20 °C (−4 °F)
+40 °C (+104
°F)
7.8 l
(2.06 gal)
10.2 l
(2.69 gal)
Travelling drive Gearbox oil
3
3. Hypoid gearbox oil based on basic mineral oil (SAE80W-90 according to DIN 51502), API GL5.
SAE80W-90
4
4. According to DIN 51502 on a mineral oil basis. Do not mix gearbox oils.
Year-round About 1.3 l each (0.34 gal)
Hydraulic oil tank
Hydraulic oil
HVLP 46
5
5. According to DIN 51524 section 3, ISO-VG 46.
Year-round
6
6. Depending on local conditions – see Hydraulics oil grade on page 5-56.
73 l (19.3 gal)
HV 46
7
7. According to ISO 6743/4.
Biodegradable oil
8
8. Biodegradable hydraulic oil based on saturated synthetic esters with an iodine value of < 10, according to DIN 51524, section 3, HVLP, HEES.
HLP Synth 46
BIOHYD SE-S 46
Grease
Roller and friction bear-
ings
KPF 2 K-20
9
,
ISO-L-X-BCEB 2
10
9. KPF 2 K-20 according to DIN 51502 multipurpose lithium grease.
10. ISO-L-X-BCEB 2 according to DIN ISO 6743-9.
Grease As required
Open transmissions
live ring: ball bearing
Live ring gears
Grease nipples
Grease nipples Multipurpose grease KPF 2 K-20
11
11. KPF 2 K-20 according to DIN 51502 multipurpose lithium grease.
Year-round As required
Battery terminals Acid-proof grease
12
12. Standard acid-proof grease NGLI category 2.
FINA Marson L2 Year-round As required
Fuel tank
Diesel fuel
13
13. Sulphur content below 0.05 %, cetane number over 45
ASTM D975-94: 1D, 2D (USA)
Summer or win-
ter diesel
depending on
outside temper-
atures
78 l (20.6 gal)
EN 590 : 96 (EU)
ISO 8217 DMX (International)
BS 2869-A1, A2 (GB)
JIS K2204 (Japan)
KSM-2610 (Korea)
GB252 (China)
Biodegradable diesel
fuel
EN 14214
ASTM D-6751
Engine cooling system Coolant
Soft water +
antifreeze SF D12 Plus
Year-round 7 l (1.85 gal)
Air conditioning
Refrigerant R134a
14
14. According to DIN 8960.
Year-round 750 g (1.65 lbs.)
Compressor oil Sanden SP10 Year-round 116.5 cm³ (7.11 in³)
Washer system Cleaning agent Water + antifreeze Year-round 2 l (0.53 gal)
Control lever base Adhesive fluid grease Förch S401 Year-round As required
