Specifications
6.31 Lift capacity table 6003 long stick, counterweight (option)
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine’s lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
5.0 m (16'-5") 4.0 m (13'-1") 3.0 m (9'-10") 2.0 (78.7 in)
A
B
Lowered blade Lowered blade Lowered blade Lowered blade Lowered blade
4.0 m
(13'-1")
1190*
(2624*)
1130
(2492)
1050*
(2315*)
1035
(2282)
3.0 m
(9'-10")
1190*
(2624*)
760
(1676)
1120*
(2469*)
1120*
(2469*)
2.0 (78.7 in)
1220*
(2690*)
395
(871)
1245*
(2745*)
845
(1863)
1375*
(3032*)
1250
(2756)
1670*
(3682*)
1670*
(3682*)
1.0 (39.4 in)
1265*
(2789*)
640
(1411)
1380*
(3043*)
850
(1874)
1690*
(3726*)
1200
(2646)
2400*
(5292*)
1815
(4002)
0.0 m (0 in)
1315*
(2900*)
700
(1543)
1485*
(3274*)
835
(1841)
1925*
(4245*)
1145
(2525)
2805*
(6185*)
1710
(3771)
−1.0 m
(−39.4 in)
1375*
(3032*)
785
(1731)
1990*
(4388*)
1120
(2470)
2855*
(6295*)
1670
(3682)
4570*
(10077*)
3240
(7144)
−2.0 m
(−78.7 in)
1425*
(3142*)
970
(2139)
2580*
(5689*)
1685
(3715)
3980*
(8776*)
3260
(7188)
Fig. 344: Lift capacity table (model 6003)
max Admissible load on extended stick
A Reach from live ring centre
B Load hook height
* Lift capacity limited by hydraulic system
With the stabilizer blade in driving direction
Without the stabilizer blade, 90° to driving direction
