BA 50Z3/6003 en – Edition 4.3 * 5003b610.fm 6-27
Specifications
6.28 Lift capacity table 6003
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine’s lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
5.0 m (16'-5") 4.0 m (13'-1") 3.0 m (9'-10") 2.0 (78.7 in)
A
B
Lowered blade Lowered blade Lowered blade Lowered blade Lowered blade
4.0 m
(13'-1")
1310*
(2889*)
1020
(2249)
1245*
(2745*)
1155
(2547)
3.0 m
(9'-10")
1300*
(2867*)
805
(1775)
1265*
(2789*)
1145
(2525)
2.0 (78.7 in)
1320*
(2911*)
710
(1566)
1330*
(2933*)
775
(1709)
1490*
(3285*)
1100
(2425)
1885*
(4156*)
1700
(3748)
1.0 (39.4 in)
1360*
(2999*)
675
(1488)
1435*
(3164*)
750
(1654)
1775*
(2591*)
1035
(2282)
2615*
(5766*)
1550
(3418)
0.0 m (0 in)
1410*
(3109*)
690
(1521)
1495*
(3296*)
730
(1610)
1970*
(4333*)
990
(2183)
2970*
(6549*)
1470
(3241)
−1.0 m
(−39.4 in)
1465*
(3230*)
760
(1676)
1965*
(4333*)
970
(2139)
2910*
(6417*)
1450
(3197)
5010*
(11047*)
2795
(6163)
−2.0 m
(−78.7 in)
1495*
(3296*)
965
(2128)
2450*
(5402*)
1475
(3352)
4005*
(8831*)
2855
(6295)
Fig. 341: Lift capacity table (model 6003)
max Admissible load on extended stick
A Reach from live ring centre
B Load hook height
* Lift capacity limited by hydraulic system
With the stabilizer blade in driving direction
Without the stabilizer blade, 90° to driving direction
