Xerox® Phaser® 3052/3260 Service Manual
Diagnostic (EDC) Mode
General Procedures and Information
Diagnostic (EDC) Mode
Enter Diagnostic (EDC) Mode, using the steps outlined below. Refer to Section 6 General Pro-
cedures GP1, Diagnostics Entry and Exit, for detailed instructions.
1. Connect to the printer with a USB cable.
2. When the printer is in Ready mode, open the EDC ReadData application and select [Run}
in the Compressed Folders dialog box.
3. Select [Update LCD] in the EDC dialog box.
4. From the EDC window, select the <Menu> button.
NOTE: Allow 1 second for the printer to process the command before making the next
menu selection.
5. Once in EDC Mode, use the arrows to select the following sub-menus:
• NVM Read/Write
• NVM Initialize
• Test Routines
Select the <Enter> button to confirm menu selections and run diagnostics tests.
Select the <Upper Level> button to stop tests.
Select the <Exit> button to exit EDC mode.
Table 1 EDC Mode Menu
Level 1 Level 2 Level 3 Level 4
NVM Read/ Write 105 Charger MHV DC K [50-900]
106 Development Deve DC K [50-900]
107 Transfer [THV] K [50-900]
[THV] K_Dup [50-900]
109 Fuser Ready Temp [-10 - 10]
Print Temp [-10 - 10]
110 LSU LD Power K [50-900]
NVM Initialize [Yes/No]
Test Routines 100 Motor Main BLDC Status [Off]
Main BLDC Rdy Status:
[Low]
101 Clutch Tray 1 Pickup Status:
[Off]
Registration Status:
[Off]
Out Bin Full Status:
[Low]
102 Sensor Tray 1 Empty Status:
[Low]
Feed Sens Status: [Low]
Regi Sens Status: [Low]
Exit Sens Status: [Low]
105 Charger K MHV Bias Status:
[Off]
106 Development K Dev Bias Status:
[Off]
107 Transfer K THV Bias Status:
[Off]
K THV - Bias Status:
[Off]
K [THV] Bias R Status: [0]
109 Fuser Temp A Status: [0]
110 LSU LSU Mot1 Rdy Status:
[Low]
LSU Mot1 Run Status:
[Off]
LD Power4 Status:
[Off]
LSU HSync4 [Low]
Table 1 EDC Mode Menu
Level 1 Level 2 Level 3 Level 4
