Xerox Phaser 6120 Service Manual

Disassembly/Assembly List
Phaser® 6120 Color Laser Printer Service Manual
5-3
Disassembly/Assembly List
No Section Part name Ref.Page
1 Exterior parts Front Cover page 6
2 Right Cover page 6
3 Left Cover page 5
4Rear Cover page4
5 Rear Panel page 4
6 Paper Take-up Cover page 6
7 Boards PWB-P (Image Processor Board) page 9
8 PWB-A (Engine Control Board) page 12
9 Waste Toner Near Full Detection Board page 18
10 Power Unit page 14
11 High Voltage Unit page 17
12 Control Panel page 8
14 Assemblies Laser (PH) Unit page 19
15 Paper Pick-up Unit page 23
16 Other Parts Main Motor page 27
17 Developing Motor page 30
18 Rack Motor page 31
19 Power Supply Cooling Fan Motor page 28
20 Ventilation Fan Motor page 28
21 Fusing Motor page 29
22 Tray1 Paper Pick-up Solenoid page 32
23 Registration Roller Solenoid page 33
24 Pressure/Retraction Solenoid /Cleaning
Blade
page 34
25 Pressure/Retraction Solenoid /2nd Image
Transfer
page 34
26 Temperature/Humidity Sensor page 35
27 Density Sensor page 37
28 Torque Limiter page 37
29 Hard Drive** page 39

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
