Phaser® 6120 Color Laser Printer Service Manual
6-1
This section covers the following:
■ Using the Parts List on page 6-2
■ Serial Number Format on page 6-3
■ Diagrams of Main Parts on page 6-4
■ P1 External Parts on page 6-6
■ P2 Top Cover on page 6-8
■ P3 Top Cover on page 6-10
■ P4 Main Frame on page 6-12
■ P5 Left Frame on page 6-14
■ P6 Right Frame on page 6-16
■ P7 Right Frame 2 on page 6-18
■ P8 Drive Section on page 6-20
■ P9 Drive Section on page 6-22
■ P10 Drive Section on page 6-24
■ P11 Drive Section on page 6-26
■ P12 Laser (PH) Section on page 6-28
■ P13 Transfer Section on page 6-30
■ P14 Transfer Roller Section on page 6-32
■ P15 Vertical Transport Section on page 6-34
■ P16 Fusing Unit on page 6-36
■ P17 Electrical Components on page 6-38
■ P18 Paper Take-Up Section on page 6-40
■ P19 Paper Take-Up Section 2 on page 6-41
■ P20 Paper Take-Up Section 3 on page 6-43
■ P21 Wiring on page 6-45
■ P22 Wiring on page 6-46
■ P23 Wiring on page 6-47
■ P24 Wiring Accessories on page 6-48
■ P25 Accessories on page 6-49
Print Engine Parts
List

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
