Status Indicator RAPs
Workcentre PE 220 11/05 2-3
1 Initial Checks RAP
Basic Check List
1. Check the Power.
• Does "Warming Up" appear on the display?
--> If not check power cable, switch or SMPS.
--> Does the wall socket work?
• Do the Motors or other components initialize (listen for main motor, fan and LSU sounds)?
--> If not or there are none of the normal startup sounds check cable, switch or SMPS.
--> Does the wall socket work?
2. Check the LCD Panel.
• Refer to General Procedures.
• Is there any display at all?
--> If not check power cable, switch or SMPS.
• Is the display a meaningful message. Are there any broken or badly formed characters?
• Is the message on the LCD Panel a standard error message? Refer to GP 6.
--> Does the wall socket work?
--> Check the main PBA and cable harness.
--> Refer to RAP 3.
3. Check the Paper Path
• Is there a Paper Jam?
--> Remove any paper fragments caught in the paper path.
• Paper Jam occurs repeatedly at a specific point in the Paper Path
--> Open the fuser cover, Clear jam.
--> Dismantle the machine and carefully inspect the region where the jam occurs.
Especially, check if paper fragments are caught in the Fuser, refer to REP 16.
4. Print the Information Page (Configuration).
• Try printing a test page from a computer.
--> If there is an error, check cables and driver installation.
5. Check the Print Quality.
• Is there a Print Quality Problem?
--> Go to Section 3, Image Quality.
6. Check consumables (toner etc.).
• Using the keys print the Test Pattern.
--> Expected life of various consumable parts, compare this with the figures printed and
replace as required
Enter Tech mode, GP 4. Check the CRU print count. If necessary, install a new print cartridge,
PL 1.
